Atlas Copco GA11VSD+ 175 FF, 15 HP 460V Rotary Screw Air Compressor

Base mount, integrated air dryer, 69.7 CFM, 175 PSI, 460/3/60.

Features

  • Base mount
  • 15 HP
  • 69.7 CFM capacity
  • 175 PSI pressure rating
  • Integrated air dryer included
  • 460/3/60

The Atlas Copco GA11VSD+ 175 FF, 15 HP 460V Rotary Screw Air Compressor contains a compact Interior Permanent Magnet (iPM) motor that is designed for optimal cooling by oil, requiring no cooling air flow. The direct drive uses a vertical design requiring fewer parts, is oil-cooled and pressure tight, with no gears, belts, or shaft seal. The low-noise fan is complies with ERP2015 efficiency.

The integrated oil separator includes an integrated bypass valve, and an electronic no-loss water drain is included as standard for efficient removal of condensate without loss of compressed air. The unit contains a manual integrated bypass for effective condensate removal in case of power failure.

The Elektronikon® Touch controller includes warning indications, compressor shut-down and maintenance scheduling, and enables remote control via SMARTLINK to maximize performance and energy efficiency.

The sentinel valve includes no inlet arrestor and provides no blow-off or pressure drop losses, and is maintenance-free. The VSD+ cubicle keeps electrical components cool, extending lifetime, and uses a dedicated drive for iPM technology motors. A 5% DC choke is included standard. Heat dissipation of the inverter is transferred to a separate compartment.
